Pre-Galvanised Steel

See products
Perforated Metal

Pattern 223

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options


SHEET SIZE:
Up to 2400mm x 1200mm



ShapeRound hole profiles
Can be made inAluminium
Mild Steel
Pre-Galvanised Steel
Hole Dimensions4.0mm diameter
Pitch4.8mm staggered pitch
Open Area62%
View Product PDF Enquire about Pattern 223
Perforated Metal

Pattern 225

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions4.0mm diameter
Pitch6.0mm staggered pitch
Open Area40%
View Product PDF Enquire about Pattern 225
Pattern 2458 - 19x9.5mm holes, 25.4mm diagonal pitch
Perforated Metal

Pattern 2458

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions19mm & 9.5mm diameter
Pitch25.4mm diagonal
Open Area55%
View Product PDF Enquire about Pattern 2458
Pattern 2459 - 19&9.5mm diameter
Perforated Metal

Pattern 2459

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions19mm & 9.5mm diameter
Pitch25.4mm straight
Open Area55%
View Product PDF Enquire about Pattern 2459
Pattern 8423 - 20mm star shape
Perforated Metal

Pattern 8423

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeStar
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm star
Open Area57%
View Product PDF Enquire about Pattern 8423
Pattern 8652 - 45x15mm polygon shape
Perforated Metal

Pattern 8652

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapePolygon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions45mm x 15mm
Open Area62%
View Product PDF Enquire about Pattern 8652
Pattern 629 - 28mm hexagon x 33mm staggered pitch
Perforated Metal

Pattern 629

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Recent projects with Pattern 629:
Perforated Ceiling, Sarah & Sebastian, Chadstone

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions28mm hexagon
Pitch33mm staggered pitch
Open Area72%
View Product PDF Enquire about Pattern 629
Pattern 248 - 10mm round holes x 15mm staggered pitch
Perforated Metal

Pattern 248

Project with similar pattern

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel
Hole Dimensions10mm diameter
Pitch15mm staggered pitch
Open Area40%
View Product PDF Enquire about Pattern 248
Pattern242 - 9mm round holes perforated metal
Perforated Metal

Pattern 242

Project with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions9mm diameter
Pitch16mm straight pitch
Open Area25%
View Product PDF Enquire about Pattern 242
Pattern 415 - 10mm square
Perforated Metal

Pattern 415

Project with similar pattern

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions10mm x 10mm
Pitch15mm straight pitch
Open Area44%
View Product PDF Enquire about Pattern 415
Pattern 380 - 20mm round end slot
Perforated Metal

Pattern 380

Project with similar pattern

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions8mm (H) x 20mm (W)
Pitch26x14mm pitch
Open Area40%
View Product PDF Enquire about Pattern 380
Pattern 370 - 4.76x25.4mm round end slot
Perforated Metal

Pattern 370

Project with similar pattern

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions4.76mm (H) x 25.4mm (W)
Pitchstaggered
Open Area40%
View Product PDF Enquire about Pattern 370
Pattern 230 perforated metal
Perforated Metal

Pattern 230



Recent projects with Pattern 230:
Brass Balcony Balustrade, Chatswood Home

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions4.76mm diameter
Pitch6.8mm staggered pitch
Open Area44%
View Product PDF Enquire about Pattern 230
Pattern 235 - perforated metal
Perforated Metal

Pattern 235

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions6.35mm diameter
Pitch12.7mm staggered pitch
Open Area22.6%
View Product PDF Enquire about Pattern 235
Pattern 229 - perforated metal
Perforated Metal

Pattern 229

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel
Hole Dimensions4.76mm diameter
Pitch13.6mm staggered pitch
Open Area11%
View Product PDF Enquire about Pattern 229
Pattern 848 Mosaic 58x35mm diamond
Perforated Metal

Pattern 848

*The Deco collection is the latest new made-to-order release from Arrow Metal. Ideal for interior applications and exteriors that need to make a style impact.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeDiamond
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions58mm x 35mm diamond
Open Area48%
View Product PDF Enquire about Pattern 848
Pattern-622 - 20mm hexagon perforated metal
Perforated Metal

Pattern 622

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions20mm hexagon
Pitch25mm staggered pitch
Open Area64%
View Product PDF Enquire about Pattern 622
Pattern 621 - perforated metal
Perforated Metal

Pattern 621

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm hexagon
Pitch28mm staggered pitch
Open Area51%
View Product PDF Enquire about Pattern 621
Pattern 620 - 20mm hexagon perforated metal
Perforated Metal

Pattern 620

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm hexagon
Pitch32mm staggered pitch
Open Area39%
View Product PDF Enquire about Pattern 620
Pattern 614 - 14mm hexagon perforated metal
Perforated Metal

Pattern 614

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions14mm hexagon
Pitch18mm staggered pitch
Open Area60%
View Product PDF Enquire about Pattern 614
Pattern 545 - Raised perforated metal
Perforated Metal

Pattern 545

Safety Perforation
Applications: flooring, steps, architectural

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm raised holes, 14mm drain holes
Pitch45 mm straight pitch
Open Area23%
View Product PDF Enquire about Pattern 545
Patter 611 - 10mm hexagon
Perforated Metal

Pattern 611

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions10mm hexagon
Pitch25mm staggered pitch
Open Area32%
View Product PDF Enquire about Pattern 611
Pattern 2319
Perforated Metal

Pattern 2319

Recent projects with Pattern 2319:
Como Train Station,  Merrylands RSL Club,  Canterbury Public School

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions5 different diameters
Pitch 19.2mm straight pitch
Open Area23%
View Product PDF Enquire about Pattern 2319
Pattern 628 - 28mm hexagon x 33mm staggered pitch
Perforated Metal

Pattern 628

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions28mm hexagon
Pitch38mm staggered pitch
Open Area54%
View Product PDF Enquire about Pattern 628
Pattern 520 - raised perforated metal
Perforated Metal

Pattern 520

Safety Perforation
Applications: flooring, steps, architectural

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions14mm raised holes, 6.4mm drain holes
Pitch38.1mm straight pitch
Open Area11%
Stocked ItemYes
View Product PDF Enquire about Pattern 520
Pattern 524 - 20mm star raised holes
Perforated Metal

Pattern 524

Safety Perforation
Applications: flooring, steps, architectural

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm star raised holes, 6mm drain holes
Pitch38.1mm straight pitch
Open Area14%
Stocked ItemYes
View Product PDF Enquire about Pattern 524
Arrow Metal perforated metal - square holes
Perforated Metal

Pattern 449

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions30mm x 30mm
Pitch40mm diagonal pitch
Open Area56%
View Product PDF Enquire about Pattern 449
Perforated Metal

Pattern 368

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions3.2mm (H) x 19mm (W)
Pitchstaggered
Open Area41%
View Product PDF Enquire about Pattern 368
Perforated Metal

Pattern 382

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions12mm (H) x 30mm (W)
Pitchstaggered
Open Area37%
View Product PDF Enquire about Pattern 382
Perforated Metal

Pattern 287

Recent projects with Pattern 287:
Aluminium Perforated Sheet, ASICS Oceania HQ

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions70mm diameter
Pitch100mm staggered pitch
Open Area44%
View Product PDF Enquire about Pattern 287
Perforated Metal

Pattern 284

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions40mm diameter
Pitch50mm staggered pitch
Open Area58%
View Product PDF Enquire about Pattern 284
Perforated Metal

Pattern 397

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRectangle
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions8mm (H) x 75mm (W)
Pitchstraight
Open Area48%
View Product PDF Enquire about Pattern 397
Perforated Metal

Pattern 396



Recent projects with Pattern 396:
Perforated Metal Ceiling, Waitara Station

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRectangle
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions8mm (H) x 75mm (W)
Pitchstaggered
Open Area48%
View Product PDF Enquire about Pattern 396
Perforated Metal

Pattern 392

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRectangle
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions7mm (H) x 52mm (W)
Pitchstaggered
Open Area43%
View Product PDF Enquire about Pattern 392
Perforated Metal

Pattern 391

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRectangle
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions6.35mm (H) x 31.75mm (W)
Pitchstaggered
Open Area43%
View Product PDF Enquire about Pattern 391
Perforated Metal

Pattern 384

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions16mm (H) x 40mm (W)
Pitchstaggered
Open Area40%
View Product PDF Enquire about Pattern 384
Perforated Metal

Pattern 379

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions7mm (H) x 52mm (W)
Pitchstraight
Open Area42%
View Product PDF Enquire about Pattern 379
Perforated Metal

Pattern 378

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions7mm (H) x 52mm (W)
Pitchstaggered
Open Area42%
View Product PDF Enquire about Pattern 378
Perforated Metal

Pattern 377

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions7mm (H) x 25mm (W)
Pitchstraight
Open Area45%
View Product PDF Enquire about Pattern 377
Perforated Metal

Pattern 376

Projects with Pattern 376:
Perforated metal screen walls, University of Newcastle

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound end slot
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions7mm (H) x 25mm (W)
Pitchstaggered
Open Area45%
View Product PDF Enquire about Pattern 376
Arrow Metal perforated metal P610 - hexagon 10mm
Perforated Metal

Pattern 610

*The Cosmic collection offers a wide choice of hexagon hole arrangements to suit all types of interior and exterior architecture and design projects.

Projects with similar pattern.

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeHexagon
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions10mm hexagon
Pitch12.5mm
Open Area64%
View Product PDF Enquire about Pattern 610
Perforated Metal

Pattern 448

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions30mm x 30mm
Pitch40mm staggered pitch
Open Area56%
View Product PDF Enquire about Pattern 448
Perforated Metal

Pattern 435

Projects with Pattern 435:
Perforated metal balustrade in residential home, Sydney

Please refer to PERFORATED METAL SPECIFICATION TABLEfor more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRadiused Square
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions20mm x 20mm
Pitch25mm diagonal pitch
Open Area60%
View Product PDF Enquire about Pattern 435
Perforated Metal

Pattern 434

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRadiused Square
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions20mm x 20mm
Pitch25mm straight pitch
Open Area60%
View Product PDF Enquire about Pattern 434
Perforated Metal

Pattern 433

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm x 20mm
Pitch35mm staggered pitch
Open Area33%
View Product PDF Enquire about Pattern 433
Perforated Metal

Pattern 432

Projects with Pattern 432:
Perforated metal balustrade in residential home

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions20mm x 20mm
Pitch35mm straight pitch
Open Area33%
View Product PDF Enquire about Pattern 432
Perforated Metal

Pattern 424

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions15mm x 15mm
Pitch20mm straight pitch
Open Area56%
View Product PDF Enquire about Pattern 424
Perforated Metal

Pattern 419

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions11.1mm x 11.1mm
Pitch15.9mm staggered pitch
Open Area49%
View Product PDF Enquire about Pattern 419
Perforated Metal

Pattern 418

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions11.1mm x 11.1mm
Pitch15.9mm straight pitch
Open Area49%
Stocked ItemYes
View Product PDF Enquire about Pattern 418
Perforated Metal

Pattern 413

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions8mm x 8mm
Pitch12mm straight pitch
Open Area44%
View Product PDF Enquire about Pattern 413
Perforated Metal

Pattern 412

Project with similar pattern

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Galvanneal
Mild Steel
Pre-Galvanised Steel
Hole Dimensions8mm x 8mm
Pitch11mm straight pitch
Open Area53%
Stocked ItemYes
View Product PDF Enquire about Pattern 412
Perforated Metal

Pattern 405

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeSquare
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions6.35mm x 6.35mm
Pitch16.7mm staggered pitch
Open Area29%
View Product PDF Enquire about Pattern 405
Perforated Metal

Pattern 261

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions25.4mm diameter
Pitch35mm straight pitch
Open Area41%
View Product PDF Enquire about Pattern 261
Perforated Metal

Pattern 260

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions25.4mm diameter
Pitch35mm staggered pitch
Open Area48%
View Product PDF Enquire about Pattern 260
Perforated Metal

Pattern 259

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions19mm diameter
Pitch25.4mm straight pitch
Open Area44%
View Product PDF Enquire about Pattern 259
Perforated Metal

Pattern 258

Recent projects with Pattern 258:
Decorative Perforated Panels, Westin Hotel Perth

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions19mm diameter
Pitch25.4mm staggered pitch
Open Area51%
Stocked ItemYes
View Product PDF Enquire about Pattern 258
Perforated Metal

Pattern 255

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions15mm diameter
Pitch25mm staggered pitch
Open Area33%
View Product PDF Enquire about Pattern 255
Perforated Metal

Pattern 253

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions12.7mm diameter
Pitch22.9mm pitch
Open Area24%
View Product PDF Enquire about Pattern 253
Perforated Metal

Pattern 252

Recent projects with Pattern 252:
Commercial Furniture, The Sherwood, Macarthur

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions12.7mm diameter
Pitch17.3mm staggered pitch
Open Area49%
Stocked ItemYes
View Product PDF Enquire about Pattern 252
Perforated Metal

Pattern 247

Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.

Learn more about Finishing Options

ShapeRound hole profiles
Can be made inAluminium
Brass
Galvanneal
Mild Steel
Pre-Galvanised Steel
Stainless Steel Grade 304
Stainless Steel Grade 316
Hole Dimensions9.5mm diameter
Pitch18.9mm pitch
Open Area20%
View Product PDF Enquire about Pattern 247

Enquire about

Please provide FULL delivery address if requesting SAMPLES. Must be physical address, not a PO Box.
Hidden
Drop files here or
Accepted file types: jpg, png, pdf, doc, docx, xls, xlsx, csv, Max. file size: 5 MB.
    This field is for validation purposes and should be left unchanged.

    Sign up to receive our newsletter

    • This field is for validation purposes and should be left unchanged.
