Pattern 380
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 8mm (H) x 20mm (W) | |
| 26x14mm pitch | |
| 40% |
Pattern 370
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 4.76mm (H) x 25.4mm (W) | |
| staggered | |
| 40% |
Pattern 368
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Galvanneal Mild Steel Pre-Galvanised Steel |
| 3.2mm (H) x 19mm (W) | |
| staggered | |
| 41% |
Pattern 382
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 12mm (H) x 30mm (W) | |
| staggered | |
| 37% |
Pattern 384
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 16mm (H) x 40mm (W) | |
| staggered | |
| 40% |
Pattern 379
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 7mm (H) x 52mm (W) | |
| straight | |
| 42% |
Pattern 378
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 7mm (H) x 52mm (W) | |
| staggered | |
| 42% |
Pattern 377
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 7mm (H) x 25mm (W) | |
| straight | |
| 45% |
Pattern 376
Projects with Pattern 376:
Perforated metal screen walls, University of Newcastle
Please refer to PERFORATED METAL SPECIFICATION TABLE for more details on metal types and metal thickness availability for each pattern.
Learn more about Finishing Options
| Shape | Round end slot |
| Can be made in | Aluminium Brass Galvanneal Mild Steel Pre-Galvanised Steel Stainless Steel Grade 304 Stainless Steel Grade 316 |
| 7mm (H) x 25mm (W) | |
| staggered | |
| 45% |
